RTX 4060

RTX 4060 Specifications

The RTX 4060 is based on the Ada Lovelace architecture and manufactured using the 5 nm process node. It was launched approximately 1 year, 11 months ago, originally priced at $299. It features 3072 cores, including 24 compute units (SMs), 96 texture mapping units (TMUs), and 48 render output units (ROPs). For ray tracing and AI-accelerated tasks, it also includes 24 dedicated RT cores and 96 Tensor cores, enabling advanced rendering and upscaling features where supported. It has a base clock of 1830 MHz and a boost clock reaching up to 2460 MHz. The RTX 4060 comes equipped with 8 GB of GDDR6 memory across a 128-bit bus. Memory runs at 2125 MHz and delivers a total memory bandwidth of 272 GB/s.

This GPU has a low thermal design power (TDP) of 115 W. It is generally compatible with almost all PC cases and is excellent for SFF and compact systems where heat dissipation is a concern.

RTX 4060 Performance

RTX 4060 is an entry-level graphics card with a relative gaming performance score of 30.92%. It performs well at 1080p resolution and can handle 1440p or even 4K with reduced settings or advanced features like DLSS, FSR, and frame generation. Ideal for casual gamers or users who occasionally play games on their work or general-purpose PCs without spending heavily on a GPU.

RTX 4060 delivers a balanced gaming performance-per-price ratio of 48.8%. It provides good value for users looking for a practical balance between cost and gaming capabilities.
