MSI Gaming RTX 5060 Ti 16G Ventus 2X OC Plus

RTX 5060 Ti 16GB Specifications

The RTX 5060 Ti 16GBis based on the Blackwell 2.0 architecture and manufactured using the 4 nm process node. It was launched approximately 2 weeks, 3 days ago, originally priced at $430. It features 4608 cores, including 36 compute units (SMs), 144 texture mapping units (TMUs), and 48 render output units (ROPs). For ray tracing and AI-accelerated tasks, it also includes 36 dedicated RT cores and 144 Tensor cores, enabling advanced rendering and upscaling features where supported. It has a base clock of 2407 MHz and a boost clock reaching up to 2572 MHz. The RTX 5060 Ti 16GB comes equipped with 16 GB of GDDR7 memory across a 128-bit bus. Memory runs at 1750 MHz and delivers a total memory bandwidth of 448 GB/s.

This GPU has a low thermal design power (TDP) of 180 W. It is generally compatible with almost all PC cases and is excellent for SFF and compact systems where heat dissipation is a concern.

RTX 5060 Ti 16GB Performance

RTX 5060 Ti 16GB is a mid-range graphics card, scoring 47.23% in relative gaming performance. It provides excellent performance at 1440p resolution and is capable of delivering playable 4K gaming with optimized settings or technologies like DLSS, FSR, and frame generation. This GPU is well-suited for average gamers who want 100+ FPS in competitive games at 1440p or a reasonable 4K experience in less demanding titles.

RTX 5060 Ti 16GB delivers a balanced gaming performance-per-price ratio of 48.5%. It provides good value for users looking for a practical balance between cost and gaming capabilities.
